EEHZA1V470P
Free Sample
Availability
Deliverable in short time
More information about samples availability can be found here: Availability
105°C SMD Hybrid E-Cap ZA-series
Product Code:
254794
Weight: 0.64 g
Manufacturer: PANASONIC
Weight: 0.64 g
Manufacturer: PANASONIC
Detailed information
105°C SMD Aluminum-Polymer-Hybrid Electrolytic Capacitor EEHZA1V470P with 10.000h guaranteed life time, low ESR and high ripple current capability - AEC-Q200 certified
Your technical contact person
For general questions
Manufacturer / Brand
Manufacturer: PANASONIC
Technical Product Information
| Capacitance | 47µF |
|---|---|
| Capacitance Tolerance | +/-20 % |
| Rated Ripple Current @100kHz | 1300mA rms |
| Rated Ripple Current @120Hz | 0mA rms |
| Impedance/ESR | 0,06Ω |
| Maximum Category Temperature | 105°C |
| Minimale Category Temperature | -55°C |
| Guaranteed Lifetime | 10000h |
| Pin Type | SMD |
| Diameter | 6,3mm |
| Height | 5,8mm |
| Series | ZA |
| Voltage Type | DC |
| Rated Voltage | 35Vdc |
