C410 DK
€660.80
Availability
Immediately deliverable
More information about samples availability can be found here: Availability
Development Kit for C410 SOM
Product Code:
294907
Weight: 0 g
Manufacturer: THUNDERCOMM
Weight: 0 g
Manufacturer: THUNDERCOMM
Detailed information
Camera Mezzanine Board:
Mezz A: 2 x IMX577
Mezz B: 1 x IMX347 / 1 x IMX334 (3x Optical Zooming)
Mezz C: 1 x IMX415 + 1 x HDMI IN
Display Interfaces:
1 x DP; 1 x 5.0" TFT-LCD;
Audio Interfaces:
1 x 3.5mm headset
6 x Digital Mics(From External Codec)
2 x Speaker out (From Codec)
General Interfaces on Mother Board:
1 x USB 3.1 Type C
1 x USB 2.0 Type A
1 x Micro USB(For Debug)
1 x SD card;
1 x GbE Ethernet
1 x ACCELEROMETER+GYRO Sensor
1 x Wifi/Bt Antenna Connector
6 x LEDs
4 x Keys (Vol Up/Down, Force USB Boot, Power)
Dimension 120 x 250 mm
Mezz A: 2 x IMX577
Mezz B: 1 x IMX347 / 1 x IMX334 (3x Optical Zooming)
Mezz C: 1 x IMX415 + 1 x HDMI IN
Display Interfaces:
1 x DP; 1 x 5.0" TFT-LCD;
Audio Interfaces:
1 x 3.5mm headset
6 x Digital Mics(From External Codec)
2 x Speaker out (From Codec)
General Interfaces on Mother Board:
1 x USB 3.1 Type C
1 x USB 2.0 Type A
1 x Micro USB(For Debug)
1 x SD card;
1 x GbE Ethernet
1 x ACCELEROMETER+GYRO Sensor
1 x Wifi/Bt Antenna Connector
6 x LEDs
4 x Keys (Vol Up/Down, Force USB Boot, Power)
Dimension 120 x 250 mm
